Balt LED 100 Watt Driver Unit
Balt LED 100 Watt Driver Unit Balt LED 100 Watt Driver Unit

Balt LED 100 Watt Driver Unit

From £44.10

Short Description

The Balt LED 100 Watt Driver Unit has a constant voltage type power supply and Power factor correction.








Choose your Product
Options Qty Price
 Add to Basket

Product Details

Balt LED 100 Watt Driver Unit

The Balt LED 100 Watt Driver Unit has a constant voltage type power supply and power factor correction


General Specifications:

  • Designed for LED lighting and signage applications
  • UL1310 Class 2 power, unit, pass LPS
  • 100% full load burn-in tested
  • Efficiency: 84%
  • Turn on Delay: 0.8 s
  • Data sheet



  • IP Class: IP67
  • Protections included: Over current, Short circuit, Overvoltage and Overtemperature



  • Operating temperature: -30°C ~ +50°C; 20 ~ 90% humidity
  • Storage temperature: -40°C ~ +80°C; 10 ~ 95% humidity


Quantity of drivers per circuit breaker:

  • Circuit Breaker of Type B: 4 units (at 230 VAC)
  • Circuit Breaker of Type C: 8 units (at 230 VAC)



  • Input voltage range: 100 - 240VAC; (47 - 63 Hz)
  • Maximum input AC current: 0.7 A
  • Max inrush current: 65 A
  • Power factor: 0.95



  • Max load: 8 A
  • Output current: 0 - 8 A
  • Output voltage: 12 VDC
  • Output power: 96 W


Product Dimensions:

  • Size: 195mm x 65.5mm x 40.3mm
  • Weight: 889.5g


Conformity & Standards:

  • EN60950-1
  • EN61347-2-13
  • EN55015
  • EN55022 Class B
  • EN61000-3-2,3
  • EN61000-4-2,3,4,5,6,8,11
  • EN50204
  • EN55024
  • EN61547


Manufacturers Guarantee:

5 Year Guarantee

This product is covered by our Manufacturers Guarantee against component failure and defects for up to 5 years.

* Warranty is applied only and if storage, mounting and maintenance conditions, stated in the installation guide, are followed.


Product Code:

  • BP5P-V12-100.1
