Balt LED 60 Watt Driver Unit
Balt LED 60 Watt Driver Unit Balt LED 60 Watt Driver Unit

Balt LED 60 Watt Driver Unit

From £30.60

Short Description

TheBalt LED 60 Watt Driver Unit has a constant voltage type power supply and Power factor correction.

















Choose your Product
Options Qty Price
Each
£30.60
 Add to Basket

Product Details

Balt LED 60 Watt Driver Unit

The Balt LED 60 Watt Driver Unit has a constant voltage type power supply and power factor correction



General Specifications:

  • Designed for LED lighting and signage applications
  • UL1310 Class 2 power, unit, pass LPS
  • 100% full load burn-in tested
  • Efficiency: 84%
  • Turn on Delay: 0.2 s
  • Data sheet




Protection:

  • IP Class: IP67
  • Protections included: Over current, Short circuit, Overvoltage and Overtemperature




Storage:

  • Operating temperature: -30°C ~ +50°C; 20 ~ 90% humidity
  • Storage temperature: -40°C ~ +80°C; 10 ~ 95% humidity




Quantity of drivers per circuit breaker:

  • Circuit Breaker of Type B: 9 units (at 230 VAC)
  • Circuit Breaker of Type C: 16 units (at 230 VAC)




Input:

  • Input voltage range: 100 - 240VAC; (47 - 63 Hz)
  • Maximum input AC current: 0.6 A
  • Max inrush current: 65 A
  • Power factor: 0.95




Output:

  • Max load: 5 A
  • Output current: 0 - 5 A
  • Output voltage: 12 VDC
  • Output power: 60 W




Product Dimensions:

  • Size: 174mm x 55mm x 37.3mm
  • Weight: 680.5g




Conformity & Standards:

  • EN60950-1
  • EN61347-2-13
  • EN55015
  • EN55022 Class B
  • EN61000-4-2,3,4,5,6,8,11
  • EN61000-3-2,3
  • EN50204
  • EN55024
  • EN61547




Manufacturers Guarantee:

5 Year Guarantee

This product is covered by our Manufacturers Guarantee against component failure and defects for up to 5 years.

* Warranty is applied only and if storage, mounting and maintenance conditions, stated in the installation guide, are followed.




Product Code:

  • BP5P-V12-60.1
